Relay RLX1020
SGA RLX1020 single-channel SIL 3 safety relay module with line and load diagnostics for safety-related switching.
- SIL
- IP20
Contact our sales team for price and availability.
Add to Technical Proposal
Technical Specifications
| Product Type | SIL 3 Safety Relay Module with Diagnostics |
| Function | Safety-related switching with line & load diagnostics |
| Channels | 1 Channel |
| Power Supply | 24 VDC (20–30 VDC) |
| Input | 24 VDC |
| Safety Outputs | 1× DPST (NE) + 1× SPST (ND) |
| Contact Rating | 3 A @ 250 VAC / 125 VDC (resistive) |
| LEDs | Power: Green; Status: Yellow; Fault: Red |
| Dimensions | 22.5 × 99 × 114.5 mm |
| Weight | Approx. 150 g |
| Mounting | 35 mm DIN rail |
| Ingress Protection | IP20 |
| Operating Temperature | −20 to +60 °C |
Full Description
The SGA RLX1020 safety relay module is designed for safety-related switching with line and load diagnostics. This single-channel module operates from a 24 VDC supply, with an operating voltage range of 20–30 VDC. Its safety outputs comprise one DPST output in the NE configuration and one SPST output in the ND configuration. The contact rating is 3 A at 250 VAC or 125 VDC for resistive loads. Green, yellow, and red LEDs indicate power, status, and fault, respectively. The module is suitable for 35 mm DIN-rail mounting, has an IP20 ingress protection rating, and operates from −20 to +60 °C.
